32-inch 2000-brightness high-brightness LCD screen
Product Category:Direct type
Modell: MJS-HB32D-20
Größe: 32 inches
32 inches, direct backlight, high brightness LCD screen, 2000 Helligkeit, 1920*1080, automatic sensitivity, sunlight viewable
Technische Daten
| Basic Information |
Modell |
MJS-HB32D-20 |
| Screen size and type |
32″ |
| Betriebstemperatur |
0-50℃ |
| Lagertemperatur |
-20-60℃ |
| Ambient humidity |
＜90%RH |
| Structural characteristics |
Display scale |
0.672916667 |
| Dot-spacing mm (horizontal and vertical) |
0.173*0.519 |
| Auflösung |
1920*1080 |
| Display area mm (horizontal and vertical) |
698.4*392.85 |
| Visible area mm (horizontal and vertical) |
700.6*396.5 |
| Appearance size mm (horizontal and vertical thickness) |
739.6*434.1*60.5 |
| Optical properties |
Backlight method |
Straight down |
| Display mode |
IPS，Usually dark |
| Brightness specification nits |
2000 |
| Brightness management |
Automatic sensitivity |
| Contrast ratio |
1400:1 |
| Display color |
16.7M |
| Response time |
8Frau |
| Viewing angle |
178/178 |
| Electronic characteristics |
Frequency of scans（Hz） |
60 |
| Leistung(W) |
129 |
| Supply voltage(V) |
24 |
| Signal interface |
Interface type |
LVDS |
| Matching |
Power board, image driver board |
|
