| structure |
hull |
1. Type frame, body aluminum material, surface sprayed with outdoor special powder, protective ability for more than 7 années. Closed and uniform temperature technology is adopted. Meet the IP65 protection level. |
|
glass |
Tempered glass was etched with 5 mm AG |
|
Product size (mm) |
1262*732.8*86 |
|
Product Net Weight (KG) |
37.15 KG |
|
packing measurement (mm) |
1400*200*860 MM |
|
Including package weight (KG) |
42KG |
| display screen |
Displays the size |
55” |
|
Display area (mm) |
1210*680.8 |
|
Show the proportion |
16：9 |
|
resolution ratio |
1920X1080 |
|
luminance |
1000~3000nit |
|
Visual Angle |
178° horizontal / 178° vertical |
|
brightness control |
voluntarily |
|
be in a poor light |
DLED OD10 Backlighting |
| motherboard |
Compatible with a variety of versions |
Display board and Android board are recommended |
|
WIFI |
not have |
|
Play software |
Support online program release, local program update, and stand-alone mode playback |
| drive-by-wire |
Waterproof IP67 power supply |
Industrial-grade outdoor power supply |
|
Waterproof horn |
Waterproof high quality 10W speaker |
|
Lightning protection device |
Level 3 lightning protection |
|
Leakage protector |
There is leakage prevention |
|
timer |
Customized switch machine can be set by day, week and month |
| heat radiation |
Temperature and heat dissipation |
The original backlight and shell are integrated for heat dissipation to ensure that the heat of the equipment is evenly distributed in every corner of the machine |
| else |
caméra |
not have |
| operational parameter |
working temperature |
-20℃~+55℃ |
|
Humidité de travail |
5%~ 95% |
|
working voltage |
AC 220V/50Hz |
|
maximum power dissipation |
≤120W |
