Camera
|
|
Image Sensor
|
5MP CMOS
|
|
Max. Resolution
|
2880 (H) × 1620 (V)
|
|
Pixel
|
5MP
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s
|
|
S/N Ratio
|
>65 dB
|
|
Min. Illumination
|
0.005 Lux/F1.6, 30IRE, 0 Lux IR on
|
|
Illumination Distance
|
30 m (98.4 ft)
|
|
Illuminator On/Off Control
|
Auto; manual
|
|
Illuminator Number
|
1 (IR light)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed lens
|
|
Mount Type
|
M12
|
|
Focal Length
|
2.8mm;3.6mm;
|
|
Max. Aperture
|
F1.6
|
|
Field of View
|
2.8mm:H:111° V:58° D:132°
3.6mm: H:92° V:48° D:109°
|
|
Iris Type
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 0.9 m (3.0 ft)
3.6 mm: 1.6 m (5.2 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
63.6 m (208.7 ft)
|
25.4 m (83.3 ft)
|
12.7 m (41.7 ft)
|
6.4 m
(21.0 ft)
|
|
3.6 mm
|
80.0 m (262.5 ft)
|
32.0 m
(105.0 ft)
|
16.0 m
(52.5 ft)
|
8.0 m
(26.2 ft)
|
|
Video
|
|
Frame Rate
|
CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps;
NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960H
|
|
Resolution
|
5M (2880 × 1620);
4M (2560 × 1440);
1080P (1920 ×1080);
960 H (960 × 576/960 × 480)
|
|
Day/Night
|
Auto switch by ICR
|
|
BLC
|
BLC/HLC/DWDR
|
|
WDR
|
DWDR
|
|
White Balance
|
Auto; Area WB
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
2D NR
|
|
Smart IR
|
Yes
|
|
Mirror
|
Off/On
|
|
Privacy Masking
|
Off/On (8 area, rectangle)
|
|
Certifications
|
|
Certifications
|
CE (EN55032, EN55024, EN50130-4, EN62368-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
|
|
Port
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
|
|
Audio Input
|
One channel built-in mic
|
|
Power
|
|
Power Supply
|
POC (only CVI)/12V±30% DC
|
|
Power Consumption
|
Max 3.2W (12V DC, IR on); PoC (AF)
|
|
Environment
|
|
Operating Temperature
|
–40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
|
|
Storage Temperature
|
–40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
|
|
Protection Grade
|
IP67
|
|
Structure
|
|
Casing
|
Metal throughout the whole casing
|
|
Camera Dimensions
|
φ94.0 mm × 85.7 mm (φ3.70″ × 3.37″)
|
|
Net Weight
|
0.33 kg (0.73 lb)
|
|
Gross Weight
|
0.47 kg (1.04 lb)
|
